Figure 1. AP view, mid arterial phase, distal internal maxillary artery injection with visualized sphenopalatine arteries.
A woman in her sixties presented with intractable nosebleeds. Despite multiple balloon packings and cauterizations, she continued to have episodes of repeated bleeds. The epistaxis was severe enough to require multiple units of blood transfusions on two separate occasions. She was on blood thinners for cardiac stent implants.
Figure 2a. Lateral view, external carotid artery injection. Filling of the internal maxillary artery. SpAa (sphenopalatine arteries), IMA (internal maxillary artery), OccA (occipital artery), FacA (facial artery).
Figure 2b. Lateral view, mid arterial phase, distal internal maxillary artery injection with visualized sphenopalatine arteries
Embolization of the sphenopalatine arteries on the right (Fig. 1 and 2) was performed using Polyvinyl Alcohol (PVA) particles which cured the epistaxis (Fig. 3). The post-
Figure 3a. Post-embolization, AP view, mid arterial phase, distal internal maxillary artery injection. Occluded sphenopalatine arteries (dotted circle).
Figure 3b. Post-embolization, lateral view, mid arterial phase, distal internal maxillary artery injection. Occluded sphenopalatine arteries (dotted circle). using Polyvinyl Alcohol (PVA) particles which cured the epistaxis (Fig. 3). The postoperative course was uneventful.
Epistaxis is a common problem that can usually be controlled with local measures. Of the 8 Million Americans on blood thinners, three-quarters are concerned about bleeding and have changed their activities1. Nearly 1/3 people on blood thinners have limited their travel. Patients on blood thinners represent 2/3 of patients hospitalized for epistaxis. Severe epistaxis, requiring prolonged hospitalization or later readmissions have been associated with bleeding not in the anterior nose, recurrent bleeding, no electrocoagulation, blood transfusion, male sex, anticoagulant use (odds ratio 1.731; 95%-CI = 1.046–2.865), hypertension, and hereditary hemorrhagic telangiectasia (OR 13.216; 95%-CI 5.102–34.231)2.
Nasal packing and cauterization of anterior nasal bleeds are usually effective. In patients that have failed these routine measures, trans-arterial embolization or endoscopic sphenopalatine artery ligation offer high success rates and relatively low morbidity. Trans-arterial angiogram and embolization is prudent in those posterior nasal bleeds where the anatomy and bleeding site are unclear.
